Upfitting, priced by the item
Ten items, each with a price, a weight, a lead time and a note about what it means at turn in. Everything is fitted in our bay on the same site as the yard, so no vehicle is transported twice.
Day 0 to day 3
A bare cargo bay to a working one, without a single self-tapping screw.
After, day 3
Before, day 0- Day 0. Unit lands at the yard. Bare floor, bulkhead fitted, nothing drilled.
- Day 1. Bulkhead port, LED lighting and the fused accessory take-off go in.
- Day 2. Shelving bays bolted through with sealing washers, never self-tapped.
- Day 3. Cast vinyl wrap laminated, telematics paired, keys coded, unit released.
The catalogue
Monthly figures show the cost of capitalising the item across a 36 month term at a 0.00175 money factor. Pay up front instead if you intend to transfer it into the next unit.
Steel shelving, three bay
Three bays down the driver side with adjustable dividers, a parts bin wall and a bolt-through mount with sealing washers so the holes close cleanly at turn in.
- Up front
- $1,840
- Capitalised, 36 months
- $54/mo
- Lead time
- 3 days
- Added weight
- 268 lb
At turn in Mount holes sealed at fitting, so no hole-sealing charge applies.
Composite shelving, lightweight
Same three bay layout in a composite material that saves 127 lb against steel. On a payload-limited van that is most of a second technician's kit.
- Up front
- $2,350
- Capitalised, 36 months
- $69/mo
- Lead time
- 4 days
- Added weight
- 141 lb
At turn in Mount holes sealed at fitting. Panels are replaceable individually if damaged.
Drop-down ladder rack
Gas strut assisted, drops to shoulder height on one side. Rated to 500 lb static and fitted to the factory roof mounting points, never drilled.
- Up front
- $1,480
- Capitalised, 36 months
- $44/mo
- Lead time
- 2 days
- Added weight
- 96 lb
At turn in No roof penetration, so no sealing charge at turn in.
Solid steel bulkhead partition
Full height, solid, with an optional sliding window port. Fitted as standard on most of our van stock; priced here for chassis and crew conversions.
- Up front
- $760
- Capitalised, 36 months
- $22/mo
- Lead time
- 1 day
- Added weight
- 74 lb
At turn in Standard on most units. Removal at turn in is not required.
Interior LED lighting kit
Two rows of load-area LED with a door trigger and a manual override, wired through a fused take-off rather than spliced into the factory loom.
- Up front
- $340
- Capitalised, 36 months
- $10/mo
- Lead time
- 1 day
- Added weight
- 9 lb
At turn in Fused take-off, so no spliced-loom charge at turn in.
Cross-bed tool drawer system
Four drawer aluminium unit on slides rated to 300 lb per drawer, with a keyed-alike lock set matched to the vehicle fleet key.
- Up front
- $2,050
- Capitalised, 36 months
- $61/mo
- Lead time
- 3 days
- Added weight
- 312 lb
At turn in Bolted to the bed rails, not the bed floor. Removal leaves no penetration.
Service body conversion
Steel service body with eight external compartments, a bolt-on crane plate and a compressed air provision. The longest lead time in the catalogue, so order it with the chassis.
- Up front
- $8,600
- Capitalised, 36 months
- $254/mo
- Lead time
- 12 days
- Added weight
- 1180 lb
At turn in Body stays with the unit at turn in, which is worth about six residual points.
Inverter and auxiliary battery
2,000 W pure sine inverter on a second battery with a split charge relay, so running a press or a laptop station never leaves you with a flat starter battery.
- Up front
- $1,150
- Capitalised, 36 months
- $34/mo
- Lead time
- 2 days
- Added weight
- 88 lb
At turn in Wired through the upfitter switch bank. No loom splicing.
Telematics unit and subscription
OBD-linked GPS with engine fault codes, idle time and driver scoring. Hardware is charged once; the subscription is $22 per vehicle per month and cancellable with 30 days notice.
- Up front
- $180
- Capitalised, 36 months
- $5/mo
- Lead time
- 1 day
- Added weight
- 1 lb
At turn in We remove the unit at turn in at no charge.
Full colour vehicle wrap
Full wrap in cast vinyl with a laminate, designed from your existing brand files. Cast vinyl is the point: calendered film bakes onto Texas paint and costs you the removal charge.
- Up front
- $2,900
- Capitalised, 36 months
- $86/mo
- Lead time
- 5 days
- Added weight
- 6 lb
At turn in Removal is included when we fitted it. Adhesive residue from a third party wrap is a chargeable item at $145 a vehicle.
Sample prices and lead times. Weight matters more than most fleets expect: a parts-heavy van with a steel shelving package and a full tool drawer system is carrying 580 lb before a single fitting goes in the back. Composite shelving buys 127 lb of that back.
Three rules our bay will not break
- 1
Bolt through, never self-tap
Every penetration gets a sealing washer. It costs a few minutes at fitting and saves $240 a set at turn in, and it lets the shelving transfer into your next van.
- 2
Cast vinyl with a laminate, always
Calendered film is cheaper and bonds to Texas paint. We will not fit it, because we are the ones who have to remove it in three years.
- 3
Fused take-offs, never a spliced loom
Accessory power comes from the upfitter switch bank or a fused take-off. A spliced factory loom is a $290 charge at turn in and a fault-finding nightmare in year two.
Spec the back of the van, not just the front
Tell us what your crews carry and how they work out of the vehicle. We will put a spec together with weights, lead times and the monthly cost of capitalising it.
